Specifications
| indexing mark | Thermocouple: J/K/T/E/S/N/B/R type |
| Basic Precision | 0.2 ℃ +/- 2 characters (excluding Thermocouple) |
| Temperature Measurement Range | -200~1300℃ |
| resolution | 0.1℃ |
| Number of channels | 8 channel |
| Sampling rate | Fast: 100ms Medium speed: 500ms Slow speed: 1s |
| correction | error correction per channel |
| comparator | Up and down super alarm |
| Interface | Mini-USB |
| Standard software | ATS42 data collection software |
| cold junction compensation | Precision: 0.5 ℃ |
| Power Supply | Input: 100-240V~ 50/60Hz 0.35A Output: 9V 1A DC |
| Power Supply | 8.4V, Li, 1400mAh rechargeable battery |
| Power Supply | Charging time: 200Min max. |
| Battery life | Luminance 30% ≥ 14 hours, luminance 50% ≥ 12 hours, luminance 100% ≥ 9 hours |
| Dimension | 90*190*31mm |
| Weight | 400g |
Packing list
machine X1, manual X1, certificate X1, warranty card X1
After-sales instructions
Warranty days: 365 days
