Specifications
| Application | Pharmaceuticals, Food, Chemicals, Synthetic Materials, Electronics, Engineering, Metallurgy, Glass, Ceramics, Biology, Agriculture, etc |
| sample characteristics | Soft/hard materials, brittle materials |
| Processing principle | Friction, impact force |
| Grinding method | Dry grinding, wet grinding, low temperature grinding, vacuum grinding |
| Regular crushing time | 5-10min |
| Feed particle size | ＜2mm |
| Minimum discharge particle size | 0.1μm |
| Processing Capacity | 400ml |
| station number | 4pcs |
| speed ratio | 1:2 |
| Rotation speed of ball mill tank | 1100rpm |
| Planetary disk diameter | 190mm |
| Planetary disk thickness | 6mm |
| Type of ball mill | Conventional type, vacuum type |
| Ball mill material | Stainless steel/nylon/polyurethane/polytetrafluoroethylene/polypropylene (PP)/polymer polyethylene (PE)/agate/aluminum oxide/zirconia |
| Grinding tank size | 25ml|50ml|100ml |
| Grinding material | Stainless steel, aluminum oxide, zirconia |
| Grinding ball size | 3mm 5mm 8mm 10mm |
| function mode | Forward operation (time can be set), reverse operation (time can be set), positive and negative alternating operation, intermittent operation (time can be set), Timer grinding (time can be set), pause, stepless speed regulation, emergency stop, restore |
| Ground time setting | Digital display, 00:00:01 to 99:59:59 |
| Intermittent operation time setting | Digital display, 00:01:00~99:59:59 |
| Intermittent operation time setting | Digital display, 00:00:01~ 99:59:59 |
| drive | Frequency converter, three-phase AC motor |
| Driving Power | 0.25kw |
| Power supply Voltage | 110-120V / 220-240V |
| Frequency | 50-60Hz |
| Power Connector | single phase |
| Dimension | 500*300*350mm |
| Net Weight | 33kg |
| Gross Weight | 49kg |
| Protection level | IP53 |
| standard | CE |
Packing list
Ball mill X1, operation manual X1, certificate of conformity X1, warranty card X1
After-sales instructions
Warranty days: 365 days
Non-artificially caused product quality problems, the manufacturer provides 1 year free warranty service
[Note] For after-sales services outside the Chinese mainland, if the instrument requires repair, the shipping and possible associated taxes shall be borne by the sender. Generation address of the manual: http://en.nbchao.com/p/5958/Specification.html , which is only used by users who purchase commodities from the NBCHAO.
