Specifications
| Power | 380V-50HZ |
| Motor Power | 5.5kw |
| Total running time | 1~9999min |
| alternate running time | 1~999min |
| Adjustable Rotation speed - revolution | 20~195rpm |
| Adjustable Rotation speed - Rotation | 40~390rpm |
| Noise level | ≤60±5dB |
| Speed regulation mode | Frequency conversion speed regulation |
| Device Weight | 468kg |
| Equipment Volume | 1400*850*1160mm |
| Processing Capacity | 40L |
| Can be equipped with ball mill tank specifications | 5~10L |
| station number | 4pcs |
| Can be equipped with ball mill tank specifications | 5L |
| Transmission mode | gear drive |
| Operating Mode | Two or four ball milling tanks work simultaneously |
| Maximum sample loading | Two-thirds of the Volume of the ball mill tank |
| Ball mill tank Volume | 5L-50L per can, total Volume 20L-200L |
| Feed particle size | Soil material ≤ 10mm, Miscellaneous material ≤ 3mm |
| Minimum discharge particle size | 0.1μm |
| Speed regulation mode | Frequency conversion stepless speed regulation |
Packing list
machine X1, manual X1, certificate X1, warranty card X1
After-sales instructions
Warranty days: 365 days
[Note] For after-sales services outside the Chinese mainland, if the instrument requires repair, the shipping and possible associated taxes shall be borne by the sender. Generation address of the manual: http://en.nbchao.com/p/5984/Specification.html , which is only used by users who purchase commodities from the NBCHAO.
