Specifications
| application | Crushing, grinding, mixing, homogenizing, polishing, etc |
| Application | Agriculture, Chemical, Beauty, Glass, Ceramics, Spinning & weaving, Electronics, Teaching, Research, etc |
| sample characteristics | Heavy, ultra-light, high tack, strong, liquid, corrosion, easy oxidation, etc |
| pulverization principle | Friction, impact, shearing |
| Ground structure | horizontal |
| loading method | intermittent |
| Dry grinding | Yes |
| wet grinding | Yes |
| Vacuum mill | optional |
| station level | single layer |
| Ground tank station | 4pcs |
| Ball mill tank Volume | 0.5L / 1L / 1.5L / 2L / 3L / 4L / 5L |
| Rotation speed of ball mill tank | 480r/min |
| Drive shaft material | chrome plated steel |
| Drive shaft diameter | 60mm |
| Rubber roller material | rubber |
| Type of ball mill | Horizontal practical type, horizontal vacuum type |
| Ball mill material | Stainless steel, nylon, polypropylene (PP), ultra-high density polyethylene (PE), polytetrafluoroethylene, polyurethane, corundum, zirconia, agate |
| Ground ball material | Stainless steel, corundum, aluminum oxide, agate, cemented carbide, etc |
| Grinding ball size | 3-30mm |
| Ground time setting | 0-3600 minutes |
| pause time setting | 0-3600 seconds |
| drive | Frequency converter, three-phase AC motor |
| driving Voltage | 220V |
| Driving Power | 0.75kw |
| Frequency | 50Hz |
| Power Connector | single phase |
| Protection level | IP53 |
| Accessories | manual, warranty card, Certificate of conformity |
| Body size (width * depth * height) | 860*660*690mm |
| Net Weight | 90kg |
