Specifications
| Measurement principle | Magnetic Induction + eddy Current |
| Measurement range | 0~1000µm |
| margin of error | ±3% |
| resolution | 0.1μm|1μm |
| Minimum measurement surface | Φ5mm |
| Minimum radius of curvature | Convex 3mm; Concave 30mm |
| thinnest substrate | 0.5mm(F)；50mm(N) |
| probe | Line probe |
| Power Supply | 4 * AA battery |
| system language | Chinese |
| Display screen | 4-Bit LCD display |
| Weight | 260g |
| Dimension | 161*69*32mm |
| Minimum measurement surface | 5*5mm |
Packing list
Thickness gauge × 1, iron-based standard substrate × 1, aluminum-based standard substrate × 1, suitcase X1, battery X1, instruction manual X1.
After-sales instructions
Warranty days: 365 days
[Note] For after-sales services outside the Chinese mainland, if the instrument requires repair, the shipping and possible associated taxes shall be borne by the sender. Generation address of the manual: http://en.nbchao.com/p/6358/Specification.html , which is only used by users who purchase commodities from the NBCHAO.
