Specifications
| Measurement range | Standard mode: 0.7~ 200mm (in steel, standard probe); coating mode: 3.0~20mm |
| Probe style | Split probe |
| Probe Frequency | 4MHz |
| Speed of sound | 1000~9999m/s |
| measurement error | ±(1%H+0.018)mm |
| Display resolution | 0.07/0.007mm |
| Data storage | Store 500 measurements in 5 groups |
| Operating language | Chinese |
| Display | 4-Bit LCD with backlight |
| Host size | 149*73*32mm |
| Weight | 160g |
| Application | Steel, Aluminum, Titanium, Plastic Products, Ceramics, Glass and Miscellaneous Good Ultrasonic Conductors |
| Power Supply | 2 * AA alkaline battery |
| Max/min alarm preset | Yes. |
| Environmental temperature | 0~50℃ |
| Probe Frequency | 4Hz |
| micro printer | optional |
| Operating Time | 100h |
| Power consumption | Operating current must not exceed 3V |
Packing list
After-sales instructions
Warranty days: 365 days
[Note] For after-sales services outside the Chinese mainland, if the instrument requires repair, the shipping and possible associated taxes shall be borne by the sender. Generation address of the manual: http://en.nbchao.com/p/6372/Specification.html , which is only used by users who purchase commodities from the NBCHAO.
