Specifications
| Display mode | digital explicit |
| Measurement parameters | Ra、Rz、Ry、Rq、Rt、Rp、Rs、Rv、Rms(Rq)、Rmax、Rm、R3z、Rsk、Rpc、Rmr |
| Measurement range | Ra, Rq：0.01~40µm Rz,Ry,Rp,Rt,R3z, Rm：0.02~160µm Sm, S：2~4000µm Rsk：0~100% |
| Resolution | 0.01μm|0.02μm|0.04μm |
| Error of indication | ≤±10% |
| Indication variability | ≤6% |
| Sampling length | 0.25mm|0.8mm|2.5mm |
| Sensors - Materials | Displacement Differential Inductance Sensors, Diamond, 90 ° cone angle, 5μm tip radius |
| Sensors - Force Measurement | 4mN |
| Stroke length | 17.5mm |
| filter | RC、PC-RC、GAUSSIAN、D-P |
| Interface | USB |
| Power Supply | Built-in lithium-ion rechargeable battery, charging with 8.4V, 500mA, Charging time is about 3 hours |
| Dimensions | 119*47*65mm |
| Product Weight | 440g |
| Applicable standards | ISO、DIN、JIS、ANSI |
| Operating Environment | 5-40℃ |
| Sensors coasting speed | Speed = 1mm/s (sampling length is 2.5mm) Speed = 0.5mm/s (sampling length is 0.8mm); Speed = 0.135mm/s (sampling length is 0.25mm); |
Packing list
After-sales instructions
Warranty days: 365 days
