Specifications
| Measurement range | 1~160% |
| Resolution | 0.1 |
| Precision | △R457≤0.5、△Y≤1.0 |
| Zero drift | ≤0.1% |
| Indication drift | ≤0.1% |
| Error of indication | ≤0.5% |
| Repeatability | ≤0.1% |
| Mirror reflection error | ≤0.1% |
| integrating sphere | < unk > 150mm, test hole < unk > 30mm |
| Specimen size | Test plane ≥ 0019 30mm, thickness ≤ 40mm |
| Dimensions | 330*264*400mm |
| Net Weight | 20kg |
| Power Supply | AC220V 50HZ |
Packing list
machine X1, manual X1, certificate X1, warranty card X1
After-sales instructions
Warranty days: 365 days
[Note] For after-sales services outside the Chinese mainland, if the instrument requires repair, the shipping and possible associated taxes shall be borne by the sender. Generation address of the manual: http://en.nbchao.com/p/6498/Specification.html , which is only used by users who purchase commodities from the NBCHAO.
