Specifications
| Measurement principle | Magnetic Induction |
| Measurement range | 0~1200μm |
| margin of error | ±3% |
| Resolution | 1μm |
| Minimum radius of curvature | 15mm |
| probe | Split F probe |
| statistical function | Measurement Times, MAX Maximum, MIN Minimum, Average |
| icon function | without |
| Power Supply | One 6F22 9V battery |
| Standards | ISO 2178、GB 4956 |
| Calibrated Certificate | without |
| system language | Chinese |
| Display screen | 4-Bit LCD display |
| supporting software | without |
| Machine Weight | Approx. 250g |
| Machine size | 160*80*30mm |
| Minimum measurement surface | 30*30mm |
| Operating temperature | 0~40℃ |
Packing list
host x1, product certificate x1, product warranty card x1, manual x1, instrument case x1.
After-sales instructions
Warranty days: 365 days
【Attention】
The warranty period is 1 year from the date of invoice.
Consumables such as sensors and thickness specimens are not covered by the warranty.
Freight sharing limit during the warranty period: the sender pays.
Damage caused by improper use is not covered by the warranty.
[Note] For after-sales services outside the Chinese mainland, if the instrument requires repair, the shipping and possible associated taxes shall be borne by the sender. Generation address of the manual: http://en.nbchao.com/p/680/Specification.html , which is only used by users who purchase commodities from the NBCHAO.
