Specifications
| Measurement range | 1.5~200mm |
| Probe style | Split probe |
| Probe diameter | Φ7mm |
| Measurement error | ±(0.5%H+0.1)mm |
| Display resolution | 0.1mm |
| unit system | mm/inch |
| Speed of sound | 1000~9999m/s |
| Standards | GB/T 11344-2008、JJF 1126-2004 |
| Display | LCD screen |
| Operating language | Chinese |
| Application Software | without |
| Power Supply | 1 * 6F22 battery |
| power consumption | Approx. 50mw |
| Operating Time | 100h |
| Host size | 120*60*26mm |
| Weight | 400g |
| Application | Wall thickness measurement of large plates, pipes, boilers and hulls |
Packing list
host x1, probe x1, coupling agent x1, battery x1, product certificate x1, product warranty card x1, manual x1, instrument case x1.
After-sales instructions
Warranty days: 365 days
【Attention】
The warranty period is 1 year from the date of invoice.
Consumables such as sensors and thickness specimens are not covered by the warranty.
Freight sharing limit during the warranty period: the sender pays.
Damage caused by improper use is not covered by the warranty.
[Note] For after-sales services outside the Chinese mainland, if the instrument requires repair, the shipping and possible associated taxes shall be borne by the sender. Generation address of the manual: http://en.nbchao.com/p/685/Specification.html , which is only used by users who purchase commodities from the NBCHAO.
