Specifications
| Measurement range | 1.2~250mm |
| Probe style | Split probe |
| Probe diameter | Φ5mm |
| Measurement error | ±(0.5%H+0.1)mm |
| Display resolution | 0.1mm |
| unit system | mm/inch |
| Calibration method | Automatic zero calibrating |
| Speed of sound | 1000~8000m/s |
| Standards | GB/T 11344-2008、JJF 1126-2004 |
| Display | 4-Bit LCD display |
| Operating language | Chinese |
| Application Software | without |
| Environmental temperature | 0~40℃ |
| Power Supply | 6F22 Battery 1 * |
| Host size | 150*80*30mm |
| Application | In petrochemical industry, shipbuilding industry, automobile manufacturing industry, power station, machine manufacturing industry, thickness measurement and corrosion measurement of boilers, oil storage tanks, hulls, decks, tracks, machined parts, etc.; for the measured parts with rough surface corrosion, it also has strong detection ability. |
| Zero correction test block | 5 +/- 0.02mm, 45 #steel |
| shutdown mode | About 2min |
Packing list
host x1, probe x1, coupling agent x1, battery x1, product certificate x1, product warranty card x1, manual x1, instrument case x1.
After-sales instructions
Warranty days: 365 days
【Attention】
The warranty period is 1 year from the date of invoice.
Consumables such as sensors and thickness specimens are not covered by the warranty.
Freight sharing limit during the warranty period: the sender pays.
Damage caused by improper use is not covered by the warranty.
[Note] For after-sales services outside the Chinese mainland, if the instrument requires repair, the shipping and possible associated taxes shall be borne by the sender. Generation address of the manual: http://en.nbchao.com/p/687/Specification.html , which is only used by users who purchase commodities from the NBCHAO.
