Specifications
| Processing Capacity | 800~60000mL |
| Operating Mode | S1 (continuous) |
| Speed regulation mode | stepless speed regulation |
| Speed range | 2000~11000rpm |
| Rotor maximum linear velocity | 22m/s |
| Rated torque | 1.78 N.m |
| Input Power | 850W |
| output power | 500W |
| Power supply Voltage | AC 220±10%V |
| Work head specification | Φ90mm |
| Work head material | SS304 |
| Rated torque | 172 N.cm |
| Max. Processing Viscosity | 8000cp |
| Environmental temperature | ≤40℃ |
| Allowable Relative Humidity | ≤80% |
| Dimensions | 250*350*720mm |
| Machine Weight | 10.8kg |
| Minimum immersion liquid height | 50mm |
| Maximum immersion liquid height | 236mm |
| Stator standard configuration | 5mm² 20mm² 50mm² |
| Rated Frequency | 50/60 Hz |
Packing list
Mulser x1, work head x1, manual x1, warranty card x1.
After-sales instructions
Warranty days: 365 days
[Note] For after-sales services outside the Chinese mainland, if the instrument requires repair, the shipping and possible associated taxes shall be borne by the sender. Generation address of the manual: http://en.nbchao.com/p/6884/Specification.html , which is only used by users who purchase commodities from the NBCHAO.
