Specifications
| Processing Capacity | 500~40000mL |
| Operating Mode | S1 (continuous) |
| Speed regulation mode | stepless speed regulation |
| Speed range | 200~12000rpm |
| Rotor maximum linear velocity | 19m/s |
| Rated torque | 0.96 N.m |
| Input Power | 510W |
| output power | 300W |
| Power | AC 220V 50/60Hz |
| Work head specification | Φ70mm |
| Work head material | SS304 |
| Rated torque | 22.0 N.cm |
| Max. Processing Viscosity | 8000cp |
| Maximum feed particle size | 18 m/s |
| Ambient Temperature | ≤40℃ |
| Allowable Relative Humidity | ≤80% |
| Dimensions | 215*310*720mm |
| Machine Weight | 13.8kg |
| Minimum immersion liquid height | 50mm |
| Maximum immersion liquid height | 236mm |
| Stator standard configuration | 5mm² 20mm² 50mm² |
Packing list
Mulser x1, manual x1, warranty card x1
After-sales instructions
Warranty days: 365 days
【After-sales service】
1. The whole machine is guaranteed nationwide, and the warranty is one year (except for vulnerable parts and man-made damage);
2. After-sales service is provided by the original factory;
3. Free maintenance during the warranty period, and long-term technical support outside the warranty period.
[Note] For after-sales services outside the Chinese mainland, if the instrument requires repair, the shipping and possible associated taxes shall be borne by the sender. Generation address of the manual: http://en.nbchao.com/p/6888/Specification.html , which is only used by users who purchase commodities from the NBCHAO.
