Specifications
| Measurement angle | 60° |
| Measurement range | 0~199.9GU |
| Measuring Areas | 10*20mm |
| Error of indication | ±1.0Gs |
| Graduation | 0.1GU |
| Standards | JJG696－2002 |
| Operating language | Chinese |
| Dimensions | 112*35*70mm |
| Weight | 200g |
| Power | 2 AA batteries |
| Stability | Less than +/- 0.4GU/30min |
| Operating temperature | 0~40℃ |
| Standard box Weight | 45g |
| Measurement port size | 20*40mm |
| Relative Humidity | <85% |
| Operating Time | The battery can be used continuously for more than 40 hours and can measure about 10,000 data |
Packing list
host x1, plastic outer Encasement box x1, standard board box (including 1 black quartz crystal standard board) x1, instruction manual x1, certificate x1, wiping mirror cloth x1
After-sales instructions
Warranty days: 730 days
【Warranty Terms】
1. The whole machine and accessories are guaranteed for two years. Freight sharing limit during the warranty period: the sender pays
2. The following situations need to be repaired with a fee:
(1) The product fails when used under normal conditions, but exceeds the warranty period;
(2) Use under abnormal conditions, including man-made damage, liquid ingress, and battery leakage;
(3) Failure and damage caused by failure to follow the usage methods and precautions in the manual.
[Note] For after-sales services outside the Chinese mainland, if the instrument requires repair, the shipping and possible associated taxes shall be borne by the sender. Generation address of the manual: http://en.nbchao.com/p/698/Specification.html , which is only used by users who purchase commodities from the NBCHAO.
