Specifications
| Optical inspection system | Eliminate color difference Czerny-Turner (1200L/mm grating) |
| Light spectrum bandwidth | 4nm |
| Wavelength range | 195~1020nm |
| Wavelength Accuracy | ±2nm |
| Wavelength, repeability | 1nm |
| Photometric range | 0~200%T、-0.301~2.000A |
| Photometric Accuracy | 0.5%T |
| Luminosity, sexual repeability | 0.2%T |
| stray light | ≤0.3%T@360nm |
| Noise level | 100%≤0.2%T |
| stability | ±0.002A/h@500nm |
| Baseline flatness | ±0.002A/h @500nm |
| Operating Mode | T、A、C |
| printout | Thermal printer (parallel port) optional |
| display | 4-Bit LCD LED display |
| light source | Tungsten lamp, deuterium lamp |
| Dimensions | Length 50cm, width 33cm, height about 30 |
| Weight | 12kg |
| drift | ≤0.1%T |
Packing list
host X1, manual X1, certificate X1, warranty card X1
After-sales instructions
Warranty days: 365 days
1. For product quality problems caused by non-human products of instruments and equipment, the manufacturer will provide free warranty services during the warranty period;
2. There is no warranty period for fragile and consumable parts, and if you find product quality problems after receiving the goods, please apply for return and exchange within 7 days, and you will not wait for the overdue ones;
[Note] For after-sales services outside the Chinese mainland, if the instrument requires repair, the shipping and possible associated taxes shall be borne by the sender. Generation address of the manual: http://en.nbchao.com/p/7213/Specification.html , which is only used by users who purchase commodities from the NBCHAO.
