Specifications
| Optical inspection system | Single beam of light |
| Light spectrum Bandwidth | 1.8nm |
| Wavelength range | 190~1100nm |
| Wavelength Precision | +/- 0.1Nm (D2 656.1nm )， +/- 0.3nm full band |
| Wavelength Repeatability | ≤0.2nm |
| Photometric Precision | ±0.002A(0~0.5A)、±0.004A(0.5~1A)、±0.3 %T (0~100 %T) |
| Luminosity Repeatability | ±0.001A(0~0.5A)；±0.002A(0.5~1A)；±0.1%T(0~100%T) |
| stray light | ≤0.05%T |
| Stability | ±0.0005A/h@500nm |
| Baseline flatness | ±0.0015A |
| Operating Mode | T、A、C、E |
| Interface | USB port |
| printout | Parallel mouth |
| monitor | 320 * 240 Bit Highlight 6 "Large Screen LCD |
| Light source | Tungsten lamp, deuterium lamp |
| Detector | Imported silicon photodiode |
| Weight | 15kg |
| Wavelength Drive | automatic |
Packing list
machine X1, manual X1, certificate X1, warranty card X1
After-sales instructions
Warranty days: 365 days
