Specifications
| Optical inspection system | Single beam of light |
| Light spectrum bandwidth | 1nm |
| Wavelength range | 190~1100nm |
| Wavelength Accuracy | +/- 0.1Nm (D2 656.1nm )， +/- 0.3nm full band |
| Wavelength Repeatability | ≤0.1nm |
| Photometric Accuracy | ±0.002A(0~0.5A)、±0.004A(0.5~1A)、±0.2 %T (0~100 %T) |
| Luminosity Repeatability | ±0.001A(0~0.5A)；±0.002A(0.5~1A)；±0.1%T(0~100%T) |
| stray light | ≤0.03%T |
| Stability | ±0.0005A/h@500nm |
| Baseline flatness | ±0.0015A |
| Operating Mode | T、A、C、E |
| Photometric range | 0~200%T、-4~4A |
| Interface | USB interface |
| printout | Parallel mouth |
| display | 320 * 240-Bit highlight 6 "large-screen LCD |
| Light source | Tungsten lamp, deuterium lamp |
| Detector | Imported silicon photodiode |
| Weight | 15kg |
Packing list
Complete machine X1, manual X1, certificate of conformity X1, warranty card X1
After-sales instructions
Warranty days: 365 days
1. For product quality problems caused by non-human products of instruments and equipment, the manufacturer will provide free warranty services during the warranty period;
2. There is no warranty period for fragile and consumable parts, and if you find product quality problems after receiving the goods, please apply for return and exchange within 7 days, and you will not wait for the overdue ones;
[Note] For after-sales services outside the Chinese mainland, if the instrument requires repair, the shipping and possible associated taxes shall be borne by the sender. Generation address of the manual: http://en.nbchao.com/p/7225/Specification.html , which is only used by users who purchase commodities from the NBCHAO.
