Specifications
| Optical inspection system | Double beam of light (1200/mm holographic light) |
| Light spectrum Bandwidth | 1nm |
| Wavelength range | 190~1100nm |
| Wavelength Precision | ±0.3nm |
| Wavelength Repeatability | 0.1nm |
| Photometric range | 0~200%T、-0.3~3.0A、0~9999C(0~9999F) |
| Photometric Precision | ±0.3%T |
| stray light | ≤0.03%T@220nm,360nm |
| Baseline flatness | ±0.001nm |
| Interface | RS-232C serial port (printing), USB drive (Connectivity), USB HOST (connected to U disk) |
| monitor | 7-Inch color graphic LCD display with resolution 800x480 |
| Dimensions | 600*430*240mm |
| Weight | About 23kg |
| Storage | Standard 8GB memory |
| processor | Cortex_M3 frequency 120MHz |
Packing list
machine X1, manual X1, certificate X1, warranty card X1
After-sales instructions
Warranty days: 365 days
[Note] For after-sales services outside the Chinese mainland, if the instrument requires repair, the shipping and possible associated taxes shall be borne by the sender. Generation address of the manual: http://en.nbchao.com/p/7235/Specification.html , which is only used by users who purchase commodities from the NBCHAO.
