Specifications
| monitor | 8TFT color screen |
| Wavelength range | 190~1100nm |
| Optical inspection system | Double beams of light |
| Light spectrum Bandwidth | 2nm |
| Wavelength Precision | ±0.3 |
| Wavelength Repeatability | 0.1nm |
| Scanning speed | High, medium and low |
| stray light | 0.05%T@220nm,360nm |
| Baseline flatness | 0.0003A |
| Drift | 0.0003A@500nm |
| Transmittance Precision | 0.3%T |
| Light source | Tungsten lamp, deuterium lamp |
| output interface | USB Host/USB Driver/RS232/SD卡 |
| Power Supply | AC 110/220V 50/60Hz |
| Dimensions | 595*430*210mm |
| Weight | 28kg |
Packing list
machine X1, manual X1, certificate X1, warranty card X1
After-sales instructions
Warranty days: 365 days
[Note] For after-sales services outside the Chinese mainland, if the instrument requires repair, the shipping and possible associated taxes shall be borne by the sender. Generation address of the manual: http://en.nbchao.com/p/7249/Specification.html , which is only used by users who purchase commodities from the NBCHAO.
