Specifications
| monitor | LCD display |
| Force range | 200kg |
| Unit switch | NUNKUNKUNKUNKUNKUNKUNKUNKUNKUNKUNKUNKUNKUNKUNKUNK UN |
| stress unit | Pa、kPa、MPa、kgf/cm2、lbf/in2 |
| Force measurement Accuracy | ±1% |
| Analysis | 1/10000 |
| Pressurization speed | 12.5mm/min |
| Sample area | 152.4 × 12.7mm (ring pressure), 25mm × 100mm (side pressure); 25mm × 80mm (gluing), 64.5cm2 (flat pressure)/32.2cm2 |
| Upper and lower pressure plate size | 100*100mm |
| Working Travel | 180mm |
| Power | 1/4HP |
| Dimensions | 380*320*580mm |
| Weight | About 30kg |
| Power | AC 220V+10%，1∮，1.5A |
| return speed | 50 mm/min |
Packing list
Host x1
After-sales instructions
Warranty days: 365 days
【After-sales service】
1. One year warranty
2. Lifetime maintenance
3. Damage caused by human factors, or damage caused by improper use, is not covered by the warranty
[Note] For after-sales services outside the Chinese mainland, if the instrument requires repair, the shipping and possible associated taxes shall be borne by the sender. Generation address of the manual: http://en.nbchao.com/p/7343/Specification.html , which is only used by users who purchase commodities from the NBCHAO.
