YUEPING DC-2020 Thermostatic Bath 20 liters Temperature range -20 ℃~ 100 ℃

DC-2020

Thermostatic Bath

Temperature range -20~100 ℃, Temperature Fluctuation 0.05 ℃, Temperature resolution 0.01 ℃, Working tank volume 20L, slot opening size 235 * 160 * 280mm, Temperature control mode Microcomputer temperature control, PID adjustment, circulation mode Internal/external circulation

Introduction

 Yueping low-temperature constant temperature tank DC-2020 adopts microcomputer temperature control PID adjustment and self-tuning control technology, with high temperature control accuracy; it has a burnout protection function to prevent the instrument from getting out of control; the upper limit over-temperature alarm function can be set by yourself. Alarm; fully enclosed brand compressor, fast cooling, high efficiency, low noise; the instrument is stable and reliable, and the operation is very convenient; the computer corrects the deviation of the temperature measurement value, and the accuracy of the digital display is 0.01 degrees or 0.1 degrees; the circulation pump can carry out constant temperature liquid introduction Circular and controllable.

Specifications

Features

1. Low temperature constant temperature tank DC-2020 is widely used in chemical industry, petroleum, medicine, biology, physical chemistry, metrology, colleges and universities, electronic instruments, scientific research institutions and other fields for experiments, testing and enterprise production. A place with uniform temperature to conduct constant temperature tests or tests on test samples or produced products.

2. The constant temperature tank control system adopts PID automatic control, LED liquid crystal digital display mode, real-time observation data.

3. The external circulation pump can output the constant temperature liquid in the tank to the outside, and establish a second constant temperature field outside the tank to expand the scope of use.

Optional

♦Optional RS232 or RS485 communication interface to realize data transmission for remote control.

♦Procedural temperature control system can be selected, Features are:

 Large-screen LCD display, software program control, editable time/temperature curve.

 Multi-stage programmable temperature and time programs can control the process of heating, constant temperature and cooling, and the heating speed and cooling speed can be automatically controlled according to user requirements.

 Up to 30 temperature/time periods can be programmed and stored, and each program can be set to run from 0 to 9999 minutes.

 A variety of parameter setting methods: convenient and fast input keys, shift keys and increase and decrease keys, set temperature/time period and other advanced control parameters or directly adjust the stored temperature/time setting program.

Main application areas

Analytical instruments: spectrometer mass spectrometer viscometer polarimeter fermentation device rotary evaporator.

Vacuum acquisition and medical treatment: Molecular pump, diffusion pump, cooling blanket, X-ray machine, nuclear magnetic resonance accelerator.

Industrial equipment and others: laser equipment vacuum coating equipment biopharmaceutical mold machine tool vacuum furnace welding machine reaction kettle.

Packing list：1 host, 1 power cord, 1 rubber tube, 1 cover plate, 1 manual, 1 certificate/warranty card

[Note]Because the manufacturer's packaging may be updated or upgraded, the detailed packaging list shall be subject to the latest standard configuration of the manufacturer.
