YUEPING DC-3030 Thermostatic Bath Constant temperature testing or testing of specimens or manufactured products

DC-3030

Thermostatic Bath

Temperature range -30~100 ℃, Temperature Fluctuation 0.05 ℃, Temperature resolution 0.1 ℃, Working tank volume 30L, slot opening size 310 * 280 * 230mm, Temperature control mode Microcomputer temperature control, PID adjustment, circulation mode Internal/external circulation

Introduction

Yueping DC-3030 low temperature constant temperature bath is widely used in chemical industry, petroleum, medicine, biology, physical chemistry, metrology, colleges and universities, electronic instruments, scientific research institutions and other fields for experiments, testing and enterprise production. Constant temperature test or test is carried out on test samples or produced products in a place with uniform temperature. The constant temperature tank control system adopts PID automatic control, LED digital display, and the Low Temperature Circulating Bath DC0530. Its external circulation pump can output the constant temperature liquid in the tank to the outside. Establish a second constant temperature field outside the tank to expand the scope of use.

Specifications

Features

1. Yueping DC-3030 low temperature constant temperature bath adopts microcomputer temperature control PID adjustment and self-tuning control technology, with high temperature control accuracy;

2. It has the protection function of breaking the coupler to prevent the instrument from getting out of control;

3. The upper limit over-temperature alarm function can be set by yourself, and if it exceeds the range, it will alarm immediately;

4. Fully enclosed brand compressor with fast cooling, high efficiency and low noise;

5. The Yueping 30-liter low-temperature constant temperature tank works stably and reliably, and is very convenient to operate;

6. The computer corrects the deviation of the temperature measurement value, and the digital display accuracy is 0.01 degrees or 0.1 degrees;

7. The circulation pump can carry out the external circulation of constant temperature liquid and can be controlled.

Optional

♦Optional RS232 or RS485 communication interface to realize data transmission for remote control.

♦Procedural temperature control system can be selected, Features are:

 Large-screen LCD display, software program control, editable time/temperature curve.

 Multi-stage programmable temperature and time programs can control the process of heating, constant temperature and cooling, and the heating speed and cooling speed can be automatically controlled according to user requirements.

 Up to 30 temperature/time periods can be programmed and stored, and each program can be set to run from 0 to 9999 minutes.

 A variety of parameter setting methods: convenient and fast input keys, shift keys and increase and decrease keys, set temperature/time period and other advanced control parameters or directly adjust the stored temperature/time setting program.

Main application areas

Analytical instruments: spectrometer mass spectrometer viscometer polarimeter fermentation device rotary evaporator.

Vacuum acquisition and medical treatment: Molecular pump, diffusion pump, cooling blanket, X-ray machine, nuclear magnetic resonance accelerator.

Industrial equipment and others: laser equipment vacuum coating equipment biopharmaceutical mold machine tool vacuum furnace welding machine reaction kettle.

Packing list：1 host, 1 power cord, 1 rubber tube, 1 cover plate, 1 manual, 1 certificate/warranty card

[Note]Because the manufacturer's packaging may be updated or upgraded, the detailed packaging list shall be subject to the latest standard configuration of the manufacturer.
