YUEPING CH-1515 Thermostatic Water Bath Temperature range: room temperature + 25~ 150 ℃ accuracy 0.1 degrees

CH-1515

Thermostatic Bath

Temperature range 25~ 150 ℃, Temperature Fluctuation 0.1 ℃, Temperature resolution 0.1 ℃, Working tank volume 15L, slot opening size 235 * 160 * 200mm, Temperature control mode Microcomputer temperature control, PID adjustment, circulation mode Internal/external circulation

Introduction

Yueping CH1515 constant temperature tank is a 150℃ super constant temperature oil tank, controlled by a single-chip microcomputer processor, self-tuning PID adjustment, imported platinum resistance (Pt100) temperature measurement, high temperature control accuracy, small fluctuation; the instrument is stable and reliable, easy to operate Safety. Widely used in bioengineering, medicine, food, chemical industry, metallurgy, petroleum and other fields. The constant temperature oil tank CH1515 provides users with a high-precision, controlled, and uniform temperature constant place, which is ideal for research institutes and colleges and universities. The factory laboratory, the quality inspection department's favorite constant temperature bath.

Features

1. With a professional internal circulation/external circulation pump system, the internal circulation ensures uniform and constant temperature, and the external circulation pump can pass the heated liquid in the tank through the circulation pump, which can lead the constant temperature liquid in the tank to the outside to establish a second constant temperature field;

2. LED double windows digitally display the temperature measurement value and temperature setting value respectively, the digital display resolution is 0.01℃, and the touch button is easy to operate.

3. Measured value deviation correction function, the temperature accuracy can reach 0.1 degrees

4. It has an over-temperature protection function to prevent the instrument from getting out of control; the upper limit over-temperature alarm can be set by yourself, and if it exceeds the range, it will alarm immediately;

5. The liner and table top are made of high-quality stainless steel, which is corrosion-resistant and easy to clean. The instrument works stably and reliably, and the operation is very convenient.

Application

Analytical instruments: spectrometer, mass spectrometer, viscometer, polarimeter, fermentation device, rotary evaporator, etc.

Vacuum acquisition and medical treatment: supporting use of molecular pumps, diffusion pumps, cooling blankets, X-ray machines, nuclear magnetic resonance accelerators, etc.

Industrial equipment and others: laser equipment, vacuum coating equipment, biopharmaceuticals, mold machine tools, vacuum furnaces, welding machine reactors, etc.

Optional

♦Optional RS232 or RS485 communication interface to realize data transmission for remote control.

♦Procedural temperature control system can be selected, Features are:

 Large-screen LCD display, software program control, editable time/temperature curve.

 Multi-stage programmable temperature and time programs can control the process of heating, constant temperature and cooling, and the heating speed and cooling speed can be automatically controlled according to user requirements.

 Up to 30 temperature/time periods can be programmed and stored, and each program can be set to run from 0 to 9999 minutes.

 A variety of parameter setting methods: convenient and fast input keys, shift keys and increase and decrease keys, set temperature/time period and other advanced control parameters or directly adjust the stored temperature/time setting program.

Packing list：1 host, 1 power cord, 1 rubber tube, 1 cover plate, 1 manual, 1 certificate/warranty card

[Note]Because the manufacturer's packaging may be updated or upgraded, the detailed packaging list shall be subject to the latest standard configuration of the manufacturer.
