Specifications
| Measurement range | Emission-echo mode, (0.65~ 600) mm, echo-echo mode, (3~ 100) mm (45 #steel, P5EE) |
| Probe Frequency | (2.5-7）MHZ |
| Probe diameter | Thickness probe NO5 diameter 10MM, microcrystalline probe N07 diameter 6MM, high temperature probe HT5 diameter 12MM, narrow pulse thickness probe P5EE diameter 10MM, coarse crystal Probe diameter 12MM |
| minimum pipe diameter | Φ15mm×2.0mm |
| Display resolution | 0.1/0.01/0.001mm |
| error of indication | +/- 0.04mm (< 10mm ）； +/- 0.4% Hmm (> 10mm), H is the thickness of the measured object |
| Measurement speed | Single point measurement 7 times per second, scanning mode 16 times per second |
| Display | Color 320 × 240 TFT LCD screen, adjustable backlight luminance |
| Speed of sound | 1000~9999m/s |
| Thickness measurement mode | Emission-Echo Mode (P-E) and Echo-Echo Mode (E-E) |
| Probe calibrated | Zero point calibrated, two point calibrated |
| Speed of sound | support |
| display mode | Single point measurement, maximum measurement and difference measurement |
| unit system | Metric or imperial (optional) |
| Operating language | Chinese and English can be switched. |
| Storage Capacity | Can store and manage 100 groups (up to 100 per group) of thickness data |
| Communication interface | Support Bluetooth and USB2.0 communication, and the host program can be upgraded online |
| data printing | Portable Bluetooth thermal printer to print measurement reports |
| Power Supply | Two AA size alkaline batteries, can work continuously for more than 30 hours (at default luminance) |
| Power saving method | With automatic screen standby, automatic sleep, automatic shutdown and other power-saving functions |
| Working time | More than 30 hours |
| Environmental requirements | Operating temperature 0 ℃~ + 50 ℃; Storage temperature: -20 ℃~ + 70 ℃ |
| Working Relative Humidity | ≤80％ |
| Shell material | Aluminum magnesium alloy |
| Host size | 120*67*31mm |
| Machine Weight | 1.45KG |
| PC software | Yes. |
| voice broadcast data | Voice broadcast measurement results, automatic alarm beyond Measurement range |
Packing list
Instrument host x1, probe x1, software x1, USB communication cable, manual x1, coupling agent x1, AA (No. 5) battery x2, instrument case x1
After-sales instructions
Warranty days: 365 days
[Note] For after-sales services outside the Chinese mainland, if the instrument requires repair, the shipping and possible associated taxes shall be borne by the sender. Generation address of the manual: http://en.nbchao.com/p/7619/Specification.html , which is only used by users who purchase commodities from the NBCHAO.
