Specifications
| Measurement range | Emission-echo mode (0.65~ 600) mm (in steel, suitable for probe segmentation); echo-echo mode (3~ 60) mm (in steel, P5EE probe) |
| Probe Frequency | (2.5-7）MHZ |
| Probe diameter | Thickness probe NO5 diameter 10MM, microcrystalline probe N07 diameter 6MM, high temperature probe HT5 diameter 12MM, narrow pulse thickness probe P5EE diameter 10MM, coarse crystal Probe diameter 12MM |
| minimum pipe diameter | Φ15mm×2.0mm |
| Display resolution | 0.1/0.01mm |
| error of indication | +/- 0.05mm (≤ 10mm ）；（ +/- 0.5% H + 0.01) mm (> 10mm); H is the thickness of the measured object |
| Measurement speed | Single point measurement 7 times per second, scanning mode 16 times per second |
| Display | High contrast ratio segment LCD display (support EL backlight display) |
| Speed of sound | 1000~9999m/s |
| Thickness measurement mode | Emission-Echo Mode (P-E) and Echo-Echo Mode (E-E) |
| Probe calibrated | Zero point calibrated, two point calibrated |
| Speed of sound | support |
| display mode | Single point measurement, maximum measurement and difference measurement |
| unit system | Metric (mm) or imperial (inch) |
| Operating language | Chinese |
| Storage Capacity | Can store 20 sets (up to 100 Measured values each) of thickness measurement data |
| Communication interface | USB1.1 |
| data printing | Connect to computer to print |
| Power Supply | 3V (2 AA size alkaline batteries) |
| Power saving method | With automatic screen standby, automatic sleep, automatic shutdown and other power-saving functions |
| Working time | More than 50 hours (when the backlight is not turned on) |
| Environmental requirements | Operating temperature -20 ℃~ + 50 ℃; Storage temperature: -30 ℃~ + 70 ℃ |
| Working Relative Humidity | ≤90％ |
| Shell material | ABS engineering plastics |
| Host size | 150*74*32mm |
| Machine Weight | 1.3KG |
| PC software | Yes. |
| voice broadcast data | none |
Packing list
Instrument host x1, manual x1, probe x1, coupling agent x1, AA (No. 5) battery x2, instrument case x1
After-sales instructions
Warranty days: 365 days
