Specifications
| Measuring range | Emission~ echo mode 0.65~ 600mm (45 #steel, suitable for probe segments); echo~ echo mode 3~ 100mm (45 #steel, P5EE) |
| Probe frequency | 2.5~7MHz |
| Probe style | Split probe |
| Probe diameter | Thickness probe NO5Φ10MM, microcrystalline probe N07Φ6MM, high temperature probe HT5Φ12MM, narrow pulse thickness probe P5EE Φ10MM, coarse crystal probe Φ12MM |
| Lower limit of pipe measurement | F15 * 2mm |
| Measurement error | ±0.04mm(<10mm)；±0.4%H(>10mm) |
| Display resolution | 0.001mm |
| unit system | mm/inch |
| Calibrated | Zero point calibrated, two point calibrated |
| Measurement mode | Emission-Echo Mode (P-E) and Echo-Echo (E-E) Mode |
| Measurement speed | 7 times per second for single point measurement and 16 times per second for scan mode |
| Storage Capacity | 100 sets * 100 measurements |
| Sound speed range | 1000~9999m/s |
| Display | Color 320 × 240 TFT LCD, backlight brightness adjustable |
| Operating language | Chinese and English can be switched |
| Data Interface | Support Bluetooth and USB2.0 communication, the host program can be upgraded online |
| Protection class | IP65 |
| Operating Temperature | 0~50℃ |
| Relative Humidity | ≤80%RH |
| Storage temperature | -20~70℃ |
| Power | 2 * 5 AA battery |
| power consumption | With automatic screen standby, automatic sleep, automatic shutdown and other power-saving functions |
| Operating Time | 30h |
| Host size | 150*76*38mm |
| Weight | 295g |
| Data Interface | Portable Bluetooth thermal printer to print measurement reports |
Packing list
Instrument host x1, probe x1, manual x1, coupling agent x1, software x1, instrument case x1
After-sales instructions
Warranty days: 365 days
