Specifications
| Measurement range | 0.75~300mm |
| Probe Frequency | 2.5~7MHz |
| Probe style | Split probe |
| Probe diameter | Thickness measuring probe NO5Should 10MM, microcrystalline probe N07Should 6MM, high temperature probe HT5Should 12MM, coarse crystal probe N02Should 12MM |
| Lower limit of pipe measurement | Φ15*2mm |
| measurement error | ±0.05mm(≤10mm)；(±0.5%H+0.01)mm(>10mm) |
| Display resolution | 0.1Mm/0.01mm (optional) |
| unit system | mm/inch |
| Calibration method | Single point calibrated, two point calibrated |
| Measurement mode | Single point mode, scan mode |
| Measurement speed | Single point measurement 4 times per second, scanning mode 10 times per second |
| Storage Capacity | 20 groups * 99 Measured values |
| Speed of sound | 1000~9999m/s |
| Display | 128 × 64 Chinese dot matrix liquid crystal display, high luminance EL backlight |
| Operating language | Chinese |
| Interface | RS232 |
| Application Software | Yes. |
| Environmental temperature | -20~50℃ |
| Working Relative Humidity | ≤90%RH |
| Storage temperature | -30~70℃ |
| Power Supply | 3V (2 * AA alkaline battery in series) |
| power consumption | Low power design |
| Operating Time | 1000h |
| Host size | 132*76*32mm |
| Weight | 1.5KG |
| Interface | Connect to computer to print |
| Environmental temperature | -20~50℃ |
| Working Relative Humidity | ≤90%RH |
| Body material | Aluminum magnesium alloy |
| Storage temperature | -30~70℃ |
Packing list
Instrument host x1, probe x1, screw driver x1, manual x1, coupling agent x1, AA (No. 5) battery x2, instrument case x1
After-sales instructions
Warranty days: 365 days
[Note] For after-sales services outside the Chinese mainland, if the instrument requires repair, the shipping and possible associated taxes shall be borne by the sender. Generation address of the manual: http://en.nbchao.com/p/7624/Specification.html , which is only used by users who purchase commodities from the NBCHAO.
