Specifications
| Measuring range | 0.75~300mm |
| Probe frequency | 2.5~7MHz |
| Probe style | Wired probe |
| Probe diameter | Thickness probe NO5Φ10MM, microcrystalline probe N07Φ6MM, high temperature probe HT5Φ12MM, coarse crystal probe N02Φ12MM |
| Lower limit of pipe measurement | F15 * 2mm |
| Measurement error | ±0.05mm(≤10mm)；(±0.5%H+0.01)mm(>10mm) |
| Display resolution | 0.1/0.01mm |
| unit system | mm/inch |
| Calibrated | Zero point calibrated, two point calibrated |
| Measurement mode | Single point mode, scan mode |
| Measurement speed | 4 times per second for single point measurement and 10 times per second for scan mode |
| Storage Capacity | 20 sets * 100 measurements |
| Sound speed range | 1000~9999m/s |
| Sound speed storage | Can store 20 sets (up to 100 measurements each) Film thickness measurement data |
| Display | High contrast segment LCD display, high brightness EL backlight |
| Operating language | Chinese |
| Data Interface | USB1.1, can be connected to PC |
| Application software | Yes. |
| Operating Temperature | -20~50℃ |
| Relative Humidity | ≤90%RH |
| Storage temperature | -30~70℃ |
| Power | 3V (2 * AA alkalinity battery) |
| power consumption | Low power design |
| Operating Time | 100h |
| Host size | 150*74*32mm |
| Weight | 245g |
| Anti-measurement sound speed function | support |
| Operating Temperature | -20~50℃ |
| Relative Humidity | ≤90%RH |
| Body material | ABS engineering plastics |
| Storage temperature | -30~70℃ |
Packing list
Instrument host x1, probe x1, manual x1, coupling agent x1, AA (No. 5) battery x2, instrument case x1
After-sales instructions
Warranty days: 365 days
【After-sales service】
1. Two years warranty
2. Man-made damage or damage caused by improper use is not covered by the free warranty
3. After-sales service is provided by the original factory
[Note] For after-sales services outside the Chinese mainland, if the instrument requires repair, the shipping and possible associated taxes shall be borne by the sender. Generation address of the manual: http://en.nbchao.com/p/7625/Specification.html , which is only used by users who purchase commodities from the NBCHAO.
