Specifications
| Measurement principle | Magnetic Induction + eddy Current |
| Measurement range | 0~1250μm |
| margin of error | ±3% |
| resolution | 0.1μm |
| probe | Wired probe |
| statistical function | Can store 20 sets (up to 50 Measured values per set) measurement ss0064d data |
| Power Supply | 2 * AA 3V battery |
| system language | Chinese |
| Display screen | High contrast ratio segment LCD display, high luminance EL backlight |
| Interface | USB1.1 |
| Data storage | 1000 Measured values, 20 groups |
| Weight | 340g |
| Dimension | 125*67*31 mm |
| Operating temperature | -20~50℃ |
| Interface | USB |
| Battery life | More than 200h (when the backlight is not turned on) |
| Relative Humidity | ≤90%RH |
Packing list
Host x1, calibration shim x1, zero calibration base x1, manual x1, F1/N1 probe, AA battery x2, instrument case
After-sales instructions
Warranty days: 365 days
[Note] For after-sales services outside the Chinese mainland, if the instrument requires repair, the shipping and possible associated taxes shall be borne by the sender. Generation address of the manual: http://en.nbchao.com/p/7627/Specification.html , which is only used by users who purchase commodities from the NBCHAO.
