Specifications
| Measurement range | 0.65~ 500Mm (steel, depending on probe) |
| Probe Frequency | 5MHz |
| Probe diameter | Φ8mm |
| Probe contact temperature | -30~50℃ |
| Display resolution | 0.01mm |
| Calibration method | Dialog Probe, Automatic calibration |
| Speed of sound | 1250~10000m/s |
| Standards | DB 37/T1846-2011、JJF 1126-2004 |
| Display | LCD display with backlight |
| Operating language | Chinese |
| Protection level | Waterproof and oil-proof keyboard |
| Power Supply | 2 * 7 AAA battery |
| Operating Time | 100h |
| Host size | 65*98*25mm |
| Weight | 150g |
| Application | Metal materials such as steel, stainless steel, aluminum, copper, chromium alloys, and non-metallic materials such as plastics, rubber, ceramics, and Glass |
| scanning method | 16 points per second measurement, can capture the thinnest point |
Packing list
whole machine X1, ABS engineering plastic box X1, manual X1, certificate X1, warranty card X1
After-sales instructions
Warranty days: 365 days
[Note] For after-sales services outside the Chinese mainland, if the instrument requires repair, the shipping and possible associated taxes shall be borne by the sender. Generation address of the manual: http://en.nbchao.com/p/7630/Specification.html , which is only used by users who purchase commodities from the NBCHAO.
