Specifications
| Measurement range | 0.63~ 500Mm (steel, depending on probe) |
| Probe Frequency | 1MHz~10MHz |
| Calibration method | Dialog Probe, Automatic calibration |
| Speed of sound | 1250~10000m/s |
| Display | LCD display with backlight |
| Power Supply | 2 AA batteries. The continuous use time is up to 200 hours. When the battery power is insufficient, the display will flash an alarm until it automatically shuts down. |
| Display Accuracy | 0.01mm |
| scanning method | 16 points per second measurement, can capture the thinnest point |
Packing list
Machine X1, standard probe (BT-08) X1, coupling agent X1, instrument case X1, AA (No. 5) size alkaline battery X2, manual X1, certificate X1, warranty card X1
After-sales instructions
Warranty days: 365 days
[Note] For after-sales services outside the Chinese mainland, if the instrument requires repair, the shipping and possible associated taxes shall be borne by the sender. Generation address of the manual: http://en.nbchao.com/p/7631/Specification.html , which is only used by users who purchase commodities from the NBCHAO.
