Specifications
| Rated Voltage | AC100~240V |
| Rated Frequency | 50/60Hz |
| Input Power | 162W |
| output power | 110W |
| drive type | DC brushless motor |
| Max Torque | 13.1N.cm |
| Max Torque | 39.0N.cm |
| Operating Mode | S1 (continuous) |
| Operation control mode | Combined control knob |
| Speed range | 30~2000rpm |
| Speed regulation mode | stepless speed regulation |
| Timer | 1~6000min |
| Rotation speed display | OLED |
| Rotation speed dynamic detection function | Yes |
| Rotation speed memory function | Yes |
| Safety protection | Overload protection |
| Impeller fixing method | Collet |
| Rotary collet clamping range | Φ2~10mm |
| Stirringrod penetration diameter | 10mm |
| Impeller type | Three Blade Spiral Impeller |
| Processing Capacity | 20L |
| maximum viscosity | 100000mPa·s |
| Ambient Temperature | ≤40℃ |
| Allowable Relative Humidity | ≤80% |
| Protection class | IP40 |
| Dimensions | 215*310*600mm |
| Machine Weight | 7.6kg |
Packing list
Stirrer x1, warranty card x1, manual x1
After-sales instructions
Warranty days: 365 days
【After-sales service】
1. The whole machine is guaranteed nationwide, and the warranty is one year (except for vulnerable parts and man-made damage);
2. After-sales service is provided by the original factory;
3. Free maintenance during the warranty period, and long-term technical support outside the warranty period.
[Note] For after-sales services outside the Chinese mainland, if the instrument requires repair, the shipping and possible associated taxes shall be borne by the sender. Generation address of the manual: http://en.nbchao.com/p/7657/Specification.html , which is only used by users who purchase commodities from the NBCHAO.
