Specifications
| Rated Frequency | 50/60Hz |
| Input Power | 162W |
| output power | 110W |
| drive type | Brushless DC Motor |
| Max. Torque | 13.1N.cm |
| Max. Torque | 39N.cm |
| Duty Cycle | S1 (continuous) |
| Control mode | Capacitive Touch Keyboard |
| Speed range | 30~2000rpm |
| Speed regulation mode | Promise |
| Timer Range | 1~6000min |
| Rotation speed display | TFT |
| Overload protection | Yes |
| Rotation speed dynamic detection function | Yes |
| Rotation speed trend Linear dispersion | Yes |
| Rotation speed memory function | Yes |
| Impeller fixing method | Quick turn chuck |
| Rotary collet clamping range | Φ2~10mm |
| Stirringrod penetration diameter | 8 mm |
| Impeller type | Four Blade Spiral Impeller |
| Processing Capacity | 20L |
| maximum viscosity | 10000mPa.s |
| Environmental temperature | ≤40℃ |
| Allowable Relative Humidity | ≤80% |
| Protection level | IP40 |
| Dimensions of the whole machine | 215*310*600mm |
| Machine Weight | 7.6 kg |
| Impeller material | 3Cr13 stainless steel |
| Impeller material | SS 316L stainless steel |
Packing list
Stirrer x1, warranty card x1, manual x1
After-sales instructions
Warranty days: 365 days
【After-sales service】
1. The whole machine is guaranteed nationwide, and the warranty is one year (except for vulnerable parts and man-made damage);
2. After-sales service is provided by the original factory;
3. Free maintenance during the warranty period, and long-term technical support outside the warranty period.
[Note] For after-sales services outside the Chinese mainland, if the instrument requires repair, the shipping and possible associated taxes shall be borne by the sender. Generation address of the manual: http://en.nbchao.com/p/7658/Specification.html , which is only used by users who purchase commodities from the NBCHAO.
