Specifications
| maximum temperature | 1000℃ |
| Temperature range | 100~1000℃ |
| Heating Elements | wirecoil for heater |
| Furnace material | ceramic fiber |
| Furnace Volume | 2L |
| Heating power | 2.5KW |
| Temperature control Accuracy | ±2℃ |
| Heating rate | 30 minutes to heat up to the rated temperature, [Optional 30-stage program temperature control] |
| Temperature control instrument | PID adjustment |
| Thermocouple | K Indexing Nickel Chromium - Nickel Silicon Thermocouple |
| Furnace size | 200*120*80mm |
| Power supply Voltage | 220V 50Hz |
| Dimension | 580*420*660mm |
| Weight | About 40KG |
| Temperature Resolution | 1℃ |
Packing list
host X1, operation manual X1, warranty card X1, certificate of conformity X1
After-sales instructions
Warranty days: 365 days
[Note] For after-sales services outside the Chinese mainland, if the instrument requires repair, the shipping and possible associated taxes shall be borne by the sender. Generation address of the manual: http://en.nbchao.com/p/7708/Specification.html , which is only used by users who purchase commodities from the NBCHAO.
