Specifications
| Measurement principle | Eddy Current |
| Measurement range | 0~500μm |
| margin of error | ±2% |
| Resolution | 0.1μm|1μm |
| probe | Split probe |
| Standards | Method for thickness measurement eddy current of nonconductive coating on nonmagnetic metal substrate |
| Calibrated Certificate | without |
| system language | Chinese |
| Display screen | LCD screen |
| supporting software | without |
| Machine Weight | 280g |
| Machine size | 150*80*30mm |
| Operating temperature | 5~45℃ |
Packing list
host x1, probe x1, base (6063 aluminum alloy) x1, correction foil (with test report) x 1, instrument case x1
After-sales instructions
Warranty days: 365 days
1. One year warranty from the invoice date;
2. The quality problems caused by unconventional operation are not covered by the warranty, and the manufacturer provides maintenance services, and the user needs to pay separately.
[Note] For after-sales services outside the Chinese mainland, if the instrument requires repair, the shipping and possible associated taxes shall be borne by the sender. Generation address of the manual: http://en.nbchao.com/p/775/Specification.html , which is only used by users who purchase commodities from the NBCHAO.
