Specifications
| Display mode | digital display |
| Measurement range | Z-axis (vertical): 320μm (Ra = 80μm); X-axis (horizontal): 17.5mm |
| Resolution | 0.01μm|0.02μm|0.04μm|0.08μm |
| Error of indication | ≤±10％ |
| Indication variability | ≤6％ |
| Sampling length | 0.25mm|0.8mm|2.5mm |
| evaluation length | Ln= lr×n n=1~5 |
| Sensors - Radius | Ruby, sliding direction radius 40mm |
| Sensors - Materials | Natural diamond, 90 cone angle, 5 μm tip radius |
| Sensors - Force Measurement | 4mN |
| Sensors - Measurement principles | Displacement Differential Inductance |
| filter | RC、PC-RC、GAUSS、D-P |
| Power Supply | Built-in lithium polymer rechargeable battery, charged with 8.4V, 800mA charger |
| Dimensions | 112*50*47mm |
| Product Weight | 360g |
Packing list
Instrument host x1, Calibration plate x1, height bracket x1, remote control x1, USB cable x1, manual x1, standard Sensors x1, one-word screwdriver x1, charger x1, sample pad x1, instrument case x1
After-sales instructions
Warranty days: 365 days
[Note] For after-sales services outside the Chinese mainland, if the instrument requires repair, the shipping and possible associated taxes shall be borne by the sender. Generation address of the manual: http://en.nbchao.com/p/7830/Specification.html , which is only used by users who purchase commodities from the NBCHAO.
