Specifications
| Display | Digital display (128 × 64 OLED dot matrix liquid crystal (self-luminous)) |
| Measurement parameters | Ra、Rz、Ry、Rq、Rt、Rp、Rv、Rmax、R3z、RSk、RS、RSm、Rmr |
| Measuring range | Output: 0.025 ~ 12.5μm |
| resolution | 0.001µm |
| Error of indication | ≤±10% |
| Indication of variability | ≤6% |
| Sampling length | 0.25mm|0.8mm|2.5mm |
| Evaluation length | 1L~ 5L (optional, L is the sampling length) |
| Sensors - Radius | 5μm |
| Sensors - Materials | diamond |
| Sensors - Force Measurement | 4mN |
| Sensors - Angle | 90° |
| Sensors - measurement principle | inductive |
| Sensors - Longitudinal Radius | 45mm |
| Stroke length | 17.5mm/0.7inch |
| filter | RCPC-RCGAUSSD-P |
| data storage | Can store 200 sets of original data sources and waveforms |
| Data Interface | USB interface |
| Power | Built-in rechargeable lithium battery |
| Dimensions | 140*52*48mm |
| Product Weight | 440g |
| Display range | Ra、Rq：0.005-16μm；Rz、Ry、Rt、Rp、Rv、Rmax、R3z：0.02-160μm；RS、RSm：1mm；Rmr：0-100%(%Rt)；Rsk：0-100% |
| range | ± 20µm 、 ± 40µm 、 ± 80µm |
| Minimum drive stroke length | 1.3mm/0.052inch |
| Sensors - Measurement range | 160µm |
Packing list
Roughness Gauge: host x1, RS100 standard Sensors x1, multi-reticle template x1, power adapter x1, Sensors sheath x1, bracket x1, test pad x1, U disk x1, manual x1, packing list x1, certificate x1, warranty card x1
After-sales instructions
Warranty days: 365 days
1. For product quality problems caused by non-human products of instruments and equipment, the manufacturer will provide free warranty services during the warranty period;
2. There is no warranty period for fragile and consumable parts, and if you find product quality problems after receiving the goods, please apply for return and exchange within 7 days, and you will not wait for the overdue ones;
[Note] For after-sales services outside the Chinese mainland, if the instrument requires repair, the shipping and possible associated taxes shall be borne by the sender. Generation address of the manual: http://en.nbchao.com/p/7835/Specification.html , which is only used by users who purchase commodities from the NBCHAO.
