Specifications
| Measurement principle | Magnetic Induction + eddy Current |
| Measurement range | F：0~1250μm；N：0~1000μm |
| margin of error | ±3% |
| Minimum measurement surface | Φ7mm(F)；Φ5mm(N) |
| thinnest substrate | 0.5mm(F)；0.3mm(N) |
| probe | Integrated probe |
| statistical function | MAX Maximum, MIN Minimum, Average, Standard deviation |
| Power Supply | 3 * Battery |
| Calibrated Certificate | none |
| system language | Chinese |
| Display screen | Large lattice LCD screen |
| supporting software | none |
| Machine Weight | 200g |
| Machine size | 52*25*110mm |
| statistical function | Single measurement, continuous measurement |
| Operating temperature | 0~40℃ |
| Relative Humidity | 20~90%RH |
Packing list
host x1, probe x1, standard test piece x1, manual x1, certificate x1, printer x1, base x1, battery x3, warranty card x1, packing list x1.
After-sales instructions
Warranty days: 365 days
[Note] For after-sales services outside the Chinese mainland, if the instrument requires repair, the shipping and possible associated taxes shall be borne by the sender. Generation address of the manual: http://en.nbchao.com/p/7836/Specification.html , which is only used by users who purchase commodities from the NBCHAO.
