Specifications
| Measurement principle | Magnetic Induction |
| Measurement range | 0~1250μm |
| margin of error | ±3% |
| Resolution | 0.1μm|1μm |
| Minimum measurement surface | Φ7mm |
| Minimum radius of curvature | Convex 1.5mm |
| thinnest substrate | 0.5mm |
| probe | Split probe |
| statistical function | Measurement times, MAX Maximum, MIN Minimum, Average, Standard deviation |
| Power Supply | 3 * AAA 1.5V alkaline battery |
| Calibrated Certificate | none |
| system language | Chinese |
| Display screen | LCD screen |
| Data storage | 500 Measured values |
| supporting software | none |
| Machine Weight | 230g |
| Machine size | 155*68*27mm |
| statistical function | Single measurement, continuous measurement |
| Error of indication | One-point calibrated ： +/- ( 3% H + 1) μm; two-point calibrated ： +/- [( 1~ 3) % H + 1] μm |
Packing list
host x1, probe x1, standard test piece x1, manual x1, certificate x1, printer x1, base x1, battery x3, warranty card x1, packing list x1.
After-sales instructions
Warranty days: 365 days
[Note] For after-sales services outside the Chinese mainland, if the instrument requires repair, the shipping and possible associated taxes shall be borne by the sender. Generation address of the manual: http://en.nbchao.com/p/7837/Specification.html , which is only used by users who purchase commodities from the NBCHAO.
