Specifications
| Measurement principle | magnetic Induction |
| Measurement range | 0~3000μm |
| margin of error | ±2% |
| Minimum measurement surface | Φ20mm |
| Minimum radius of curvature | Convex 5mm; Concave 25mm |
| thinnest substrate | 0.5mm(F)；50μm(N) |
| probe | Line probe |
| Calibrated Certificate | none |
| Probe size | Φ15*62mm |
| Calibrated mode | Standard calibrated, one point calibrated, two point calibrated |
| Unit display | μm/mils |
| statistical function | Measurement times, MAX Maximum, MIN Minimum, Average, Standard deviation |
| Interface | USB |
| Data storage | The maximum number of batches is 10, and the storage Capacity of each group is 1000 |
| Power Supply | 2 AA batteries |
| Display screen | LCD 128 × 64 liquid crystal |
| Operating temperature | Host: 0 - 50 ℃; Probe: -10 ℃ - 70 ℃ |
| Weight | 270g |
| Dimension | 64 *115 *25 mm |
Packing list
Host × 1, zero board and thickness calibrated foil, operation manual, data transmission software and USB cable, soft package
After-sales instructions
Warranty days: 365 days
