Ander NDJ-8S Digital Viscometer Viscosity Range 10mPa·s~ 2000000Pa · s

SE
The Ander NDJ-8S digital Viscometer is a Digital Rotational Viscometer with four rotors of different specifications, and the NDJ-8S digital Viscometer is available in eight speeds.
$599.00/set
PromotionLoading...
Coupon
Model：
Certificate
Contact
Details SPEC Con
Similar products

AnDe NDJ-8S Digital ViscometerSPEC

AnDe NDJ-8S Digital ViscometerDetails

AnDe NDJ-8S Digital ViscometerPacking list

SKU
NB008002
Display
digital display
Rotor Specifications
1 #, 2 #, 3 #, 4 #(0 #optional)
Rotor speed
0.3/0.6/1.5/3/6/12/30/60rpm
Measurement Accuracy
±2%
Power
220V、50Hz；110V、60Hz
Data Interface
RS232C
Allowable Operating Temperature
5~35℃
Temperature range
-50~99 ℃ (optional semiconductor temperature probe)
temperature Accuracy
±5℃
temperature resolution
0.1℃
communication baud rate
9600
Allowable Relative Humidity
≤80%
NDJ-8S
Digital Viscometer
Ander NDJ-8S Digital Viscometer Viscosity Range 10mPa·s~ 2000000Pa · s Picture

Introduction

Ande NDJ-8S digital viscometer is an intelligent instrument based on 16-bit high-performance single-chip microprocessor technology. It has completely changed the previous gear speed regulation method, and the stepper motor can set accurate and stable precautions according to the program. A torque sensor drives the rotor to rotate at a constant speed. When the rotor is subjected to viscous resistance in the measured liquid, after detection and processing, the viscosity of the measured liquid is displayed on the screen.

NDJ-8S digital viscometer has the advantages of quick and easy operation, high measurement accuracy and anti-interference. In addition, it also has a measurement range function, and the full scale display value is 100%.

Applications

Digital viscometers are widely used to measure solvent-based adhesives, latex, biochemical products, paints, coatings, cosmetics, inks, pulp, food, starch, etc.

Pictures

Ande NDJ-8S digital viscometer display

FAQ
QDoes ANDE Digital Viscometer meet the ISO 12634 standard?
A The NDJ-8S Digital Viscometer can be referred to
QEpoxy resin Coating viscosity measurement with what material Viscometer is better?
A Measurement Coating viscosity generally can choose viscosity cup or Viscometer, viscosity cup mainly measures relative viscosity, Viscometer measures dynamic viscosity. In general, in addition to thixotropic Coating, Coatings under 150s can be coated with 4 cups, and Coatings under 20 can be coated with 1 cup. In addition, Yehui uses ISO flow cup to measure Newton-type liquid Coating viscosity, Stormer Viscometer to measure architectural coatings viscosity, and for all brush coatings, rotational viscometer or Cone and Plate Viscometer measurement can be used.
QTo do starch viscosity test, can NDJ-8S be tested?
A Hello, yes, as long as the test viscosity range of NSJ-8S meets the viscosity range of starch, it can be tested.
