MODERNER Frame 25/50/75/100 Large Frame Applicator wet-Film Applicator 90mm

Frame 25/50/75/100 (groove width 90mm)

Large Frame Applicator

Large frame type 4-sided Applicator, wet film thickness 25/50/75/100μm, Spreader width 90mm, material stainless steel, size 90 * 120mm

Introduction to Large Frame Preparer

MODERNER Frame 25/50/75/100 large Frame Applicators have three groove widths: 60mm/80mm/90mm. This large Frame Applicator is a 90mm slot width model. The Applicator is made of stainless steel, and the thickness of the coating film of the frame type 25/50/75/100 large frame Applicator is 25 μm, 50 μm, 75 μm and 100 μm.

Parameter comparison

Material and hardness value

Frame type 25/50/75/100 large frame Applicator is made of 9Cr18Mo stainless steel, which has good wear resistance and corrosion resistance. The hardness of the Applicator reaches HRC48±2.

Applications

Frame type 25/50/75/100 large frame type preparer is used to coat wet film with specified thickness to measure the hiding power, color and luster of the sample or to prepare samples, etc.

Steps for usage

1. Put the template on the platform and fix it so that the Frame Applicator does not move when it slides over.

2. Select the preparation of the appropriate wet film thickness, and place it on the short side of the sample, close to parallel or at a specified position.

3. Pour about 5 ml of the sample in front of the frame-type 25/50/75/100 large frame-type Applicator, press both ends of the Applicator with your fingers, and slide at a constant speed of 150 mm/s to finally get the desired The wet film of the wet film thickness.

4. After use, the frame Applicator should be cleaned with a suitable solvent, and the surface should be coated with oil or Vaseline.

Pictures

Packing list：Applicator x1

[Note]Because the manufacturer's packaging may be updated or upgraded, the detailed packaging list shall be subject to the latest standard configuration of the manufacturer.
