Specifications
| Working pressure of pump | 50Mpa |
| Pump plunger diameter | 10mm |
| Pump Mass | 2kg |
| Maximum pulling force of hydraulic cylinder | 40kN |
| Hydraulic cylinder center aperture | 18mm |
| Hydraulic cylinder piston stroke | 50mm |
| Hydraulic cylinder Mass | 1.8kg |
| Measurement range | 0~40KN |
| Pressure gauge Power Supply | 4.2V rechargeable battery |
| Pressure gauge Mass | 0.2kg |
| Resolution | 0.001KN |
| Pressure gauge indication error | ≤±1%F.S |
| meet the standard | GB50203-2011、JGJ145-2013 |
Packing list
machine X1, manual X1, certificate X1, warranty card X1
After-sales instructions
Warranty days: 1095 days
[Note] For after-sales services outside the Chinese mainland, if the instrument requires repair, the shipping and possible associated taxes shall be borne by the sender. Generation address of the manual: http://en.nbchao.com/p/8489/Specification.html , which is only used by users who purchase commodities from the NBCHAO.
