Specifications
| Measurement mode | manual |
| Kit diameter | 20mm/50mm |
| Range | 10KN/0~31.84MPa、10KN/0~5.09MPa |
| Resolution | 0.001KN/0.001MPa |
| Accuracy | ≤±1%F.S |
| Force unit | MPa、KN |
| meet the standard | ISO 4624:2002、GB/T 5210-2006、TB-T2965-2001 |
| Weight | 1.8Kg |
| piston stroke | 10mm |
Packing list
Host * 1, tie rod * 1, charger * 1, 20mm test block * 9, 50mm * 3, cutter * 2, grinding pad * 6, adhesive * 1, certificate of conformity, warranty card, manual, portable case
After-sales instructions
Warranty days: 1095 days
【After-sales service】
1.3 years warranty, warranty by the original factory;
2. Man-made damage or damage caused by improper use is not within the scope of free maintenance;
3. If the quality problem identified by the original factory does not affect the secondary sales, you can apply for a refund within 7 days and replace the goods within 15 days. Returns and exchanges due to selection errors will not be accepted, please confirm the specifications and models before purchasing.
[Note] For after-sales services outside the Chinese mainland, if the instrument requires repair, the shipping and possible associated taxes shall be borne by the sender. Generation address of the manual: http://en.nbchao.com/p/8582/Specification.html , which is only used by users who purchase commodities from the NBCHAO.
