Specifications
| Display mode | digital explicit |
| Measurement range | 50~300000mPa·s |
| Rotor specification | 4 kinds of rotors B1, B2, B3, B4 |
| Rotor speed | 60/100/150/200rpm |
| reproducibility | ±1%F.S |
| Measurement Accuracy | ±2%F.S |
| Power supply Voltage | AC100-240V，50Hz/60Hz，DC17V1.2A |
| Weight | 7kg |
| Encasement material | Five-layer cardboard |
| collection method | continuous acquisition |
| Capacity | 300~600ml |
| Capacity | 400 or 800ml (self-matching) |
| Lifting system | Metal lifting system |
| Bearing system | ruby |
| Torque material | beryllium bronze |
| Control system | microcomputer |
| software system | Data collection, programming, analysis |
| temperature sensor | PT100 temperature sensor |
| Encasement | aluminum alloy |
Packing list
host x1, rotor x4, manual x1, warranty card x1
After-sales instructions
Warranty days: 730 days
