Specifications
| Display mode | digital explicit |
| Measurement range | 40~80000000mPa·s |
| Rotor specification | 2 #, 3 #, 4 #, 5 #, 6 #, 7 #(1 #optional) |
| Rotor speed | 0.1~200rpm |
| reproducibility | ±0.5%F.S |
| Measurement Accuracy | ±1%F.S |
| Power supply Voltage | AC100-240V，50Hz/60Hz，DC17V1.2A |
| Interface | RS232 |
| Weight | 7kg |
| Capacity | 600Ml beaker or optional small sample adapter |
| Encasement material | Five-layer cardboard |
| collection method | continuous acquisition |
| Capacity | 300~600ml |
| Capacity | 400 or 800ml (self-matching) |
| Lifting system | Metal lifting system |
| Bearing system | ruby |
| Torque material | beryllium bronze |
| Control system | microcomputer |
| software system | Data collection, programming, analysis |
| temperature sensor | PT100 temperature sensor |
| Encasement | aluminum alloy |
| Rotation speed Control mode | Continuously variable speed (without gear drive) |
Packing list
host x1, rotor x6, manual x1, warranty card x1
After-sales instructions
Warranty days: 730 days
[Note] For after-sales services outside the Chinese mainland, if the instrument requires repair, the shipping and possible associated taxes shall be borne by the sender. Generation address of the manual: http://en.nbchao.com/p/8757/Specification.html , which is only used by users who purchase commodities from the NBCHAO.
