Specifications
| Camera system | Professional CCD Digital Camera + High Performance Microscope |
| Image resolution | 1280*1024 |
| Photo method | Single, continuous |
| Light source | LED Cold Light source with continuously adjustable luminance, uniform emission, clearer image contour and higher resolution |
| Contact angle analysis method | Theta/2 method, tangent method, can be calculated automatically or manually (corrected) |
| Measurement range of contact angle | 0~180° |
| Contact angle test resolution | 0.01° |
| Solid surface energy | Calculation of Surface Free Energy, Droplet Volume and Solid Adhesive Force by One Liquid Method and Two Liquid Method |
| Surface tension test method | without |
| Measurement range of surface tension | without |
| Surface tension test resolution | without |
| Sample stage displacement | Front and rear: 60mm; left and right 35mm; up and down 50mm, the sample stage can be adjusted horizontally, and the diameter is 90mm. |
| Sample stage size | 105*120mm |
| Maximum sample thickness | ≤35mm |
| Tilt platform | Measurement of forward/backward angle, slip angle |
| Injection method | Manual Sample injector |
| Dimension | 525*160*470mm |
| Net Weight | 12kg |
| Power supply Voltage | 220V/50Hz |
| Power | 0.2KW |
Packing list
host x1, liquid injection device x1, lens x1, CCD camera x1, micro injection needle x2, inner hexagon x1, mounting plate x1, cable x2, manual, certificate of conformity, warranty card x1, rolling angle device x1.
After-sales instructions
Warranty days: 365 days
1. For product quality problems caused by non-human products of instruments and equipment, the manufacturer will provide free warranty services during the warranty period;
2. There is no warranty period for fragile and consumable parts, and if you find product quality problems after receiving the goods, please apply for return and exchange within 7 days, and you will not wait for the overdue ones;
