Specifications
| Camera system | Professional CCD Digital Camera + High Performance Microscope Head |
| Highest resolution | 1280×1024 |
| How to take pictures | Single sheet, continuous |
| light source | LED cold light source with continuously adjustable brightness, uniform light emission, clearer image outline and higher resolution |
| Contact angle analysis method | Theta/2 method, tangent method, automatic calculation or manual (modified) calculation |
| Contact angle Measurement range | 0~180° |
| Contact angle test resolution | 0.01° |
| Solid surface energy | Calculation of surface free energy, droplet Volume and solid adhesion by one-liquid method and two-liquid method |
| Surface tension test method | S-H table method, form factor method |
| Surface tension Measurement range | 0~400mN/m |
| resolution | 0.01mN/m |
| Sample stage displacement | Front and rear: 60mm; left and right 35mm; up and down 50mm, the sample table can be adjusted horizontally, the diameter is 90mm |
| Sample stage size | 105×120mm |
| Sample Maximum Film thickness | ≤35mm |
| Tilt platform | Measurement of forward/backward angle, slip angle |
| Injection method | Manual Sample injector |
| Dimensions | 525*160*470mm |
| Net Weight | 12kg |
| Power | 220V/50Hz |
| Standards | ASTM D 724、ASTM D 5946、ISO15969 |
| power | 0.2KW |
| Surface tension Measurement range | 0~400mN/m |
Packing list
Host x1, liquid injection device x1, lens x1, CCD camera x1, micro-injection needle x2, inner hexagon x1, mounting plate x1, cable x2, manual, certificate of conformity, warranty card x1, rolling angle device x1
After-sales instructions
Warranty days: 365 days
1. For product quality problems caused by non-human products of instruments and equipment, the manufacturer will provide free warranty services during the warranty period;
2. There is no warranty period for fragile and consumable parts, and if you find product quality problems after receiving the goods, please apply for return and exchange within 7 days, and you will not wait for the overdue ones;
