NIRUN HBDV-E Digital Viscometer Viscosity Range 80~104000000MPa · s

Digital display, Measurement range 80~26000000mPa · s, Rotor specifications 2 #, 3 #, 4 #, 5 #, 6 #, 7 #(1 #optional), Rotor speed 0.3~ 100rpm, reproducibility +/- 0.5% F.S, Measurement accuracy +/- 1% F.S.
Model：
Certificate
Contact
Details SPEC CAT
Similar products

NiRun HBDV-E Digital ViscometerSPEC

NiRun HBDV-E Digital ViscometerDetails

NiRun HBDV-E Digital ViscometerPacking list

SKU
NB008850
Display mode
digital explicit
Measurement range
80~26000000mPa·s
Rotor specification
2 #, 3 #, 4 #, 5 #, 6 #, 7 #(1 #optional)
Rotor speed
0.3~100rpm
reproducibility
±0.5%F.S
Measurement Accuracy
±1%F.S
Power supply Voltage
AC100-240V，50Hz/60Hz，DC17V1.2A
Interface
RS232
Weight
7kg
Encasement material
Five-layer cardboard
collection method
continuous acquisition
Capacity
300~600ml
Capacity
400 or 800ml (self-matching)
Lifting system
Metal lifting system
Bearing system
ruby
Torque material
beryllium bronze
Control system
microcomputer
software system
Data collection, programming, analysis
temperature sensor
PT100 temperature sensor
Encasement
aluminum alloy
Rotation speed Control mode
Continuously variable speed
HBDV-E
Digital Viscometer
Digital display, Measurement range 80~26000000mPa · s, Rotor specifications 2 #, 3 #, 4 #, 5 #, 6 #, 7 #(1 #optional), Rotor speed 0.3~ 100rpm, reproducibility +/- 0.5% F.S, Measurement accuracy +/- 1% F.S.
NIRUN HBDV-E Digital Viscometer Viscosity Range 80~104000000MPa · s Picture

Features

Optional DV data acquisition and programmable software measures rheological properties

Displays the shear rate and shear stress

The stepper motor is directly driven, gearless and the speed is accurate

The LCD LCD has a blue backlight and displays a large amount of information

The maximum viscosity value that can be measured by the rotor at the current speed is displayed.

The viscosity value shows a continuous variation

When the measurement range is out, there is an alarm sound

An RTD temperature probe is standard

Bidirectional RS232 or 485 interface is standard

Computerized full-scale linear correction

AC power adapter 100V-240V, good anti-interference

Product Applications

HBDV-E digital viscometer is widely usedInks, glues、latex、Solvent-based adhesives、Polymer solution、petroleum、Paints and coatings、solventcosmetics、Milk products、*product、juices and much more.

Product display diagram

Nirun HBDV-E digital viscometer display

Optional

DV data acquisition and program-controlled analysis software

Dedicated viscosity measurement thermostatic sink

Ultra-low viscosity adapters

Small sample adapters

Standard solutions

Micro printers

Externally recirculating glass beaker

Comparison of the main parameters of Nirun DV series viscometer

ModelDV-1+PRODV-2+PRODV-3+PRODV-E
Measuring range (mPa·s)

LDV：1-200ten thousand

RDV: 1 million to 13 million

HADV: 2 million to 26 million

HBDV: 800-104000000

LDV: 1-6 million

RDV: 100-40 million

HADV: 200-80 million

HBDV: 800-320000

LDV：1-600ten thousand

RDV: 20-40 million

HADV: 100-80 million

HBDV: 500-3200000

LDV：1-200ten thousand

RDV: 1 million to 13 million

HADV: 2 million to 26 million

HBDV: 800-104000000

Rotor speed (rpm)0.3-1000.1-2000.1-2500.3-100
Number of rotors

LDV (4 types of rotors 1, 2, 3, and 4) (Rotor 0 is optional.)）

RDV, HADV, HBDV (6 rotors 2, 3, 4, 5, 6, 7) (0, 1 rotors are optional)

Measurement accuracy±1.0% (full scale)
repeatability0.5%
FAQ
QIs this digital Viscometer compliant with the JB/T9357 standard?
A This digital Viscometer is suitable for JB/T9357. Please consult customer service for detailed application definition.
QWhat size sample container can this Viscometer be used with?
A Hello, Nirun HBDV-E Viscometer is available in 400ml~ 800ml sample containers.
QWhat rotor does Nerun HBDV-E rotational viscometer come standard with?
A Hello, this HBDV-E rotational viscometer comes standard with 6 rotors No. 2, 3, 4, 5, 6, and 7 (No. 1 rotor is an option).
