RUNJIE RJ-VX-3 light drawing instrument, drawing force range 0~30kN

RUNJIE RJ-VX-3 light drawing instrument is used to test the pull-out force, the pull-out force test range is 0~30kN, RJ-VX-3 light drawing instrument hydraulic cylinder is hollow self-reset, digital display integrated design.
Model：
Certificate
Contact
Details SPEC CAT

RunJie RJ-VX-3 Light pullerSPEC

RunJie RJ-VX-3 Light pullerDetails

RunJie RJ-VX-3 Light pullerPacking list

SKU
NB008907
Measurement range
0~30KN
Cylinder stroke
50mm
Hydraulic cylinder center aperture
18mm
Accuracy
1%
Resolution
0.001KN
Cylinder Weight
1.8KG
Common anchors
Φ6-Φ12
tie rod
M16
adapter
M6-M12
meet the standard
GB 50203-2011、JGJ 145-2013
RJ-VX-3
Light puller
RUNJIE RJ-VX-3 light drawing instrument, drawing force range 0~30kN Picture

Instrument Introduction

Runjie Tiandi RJ-VX-3 light puller is composed of hand pump, hollow hydraulic cylinder, digital pressure gauge, high-pressure hose with quick connector, anchor, tie rod, adapter and portable case. The whole series of hydraulic cylinders is a hollow self-centering, digital display integrated design, which can directly read the force value (KN), and has the functions of peak holding, storage, clearing, backlight, query and automatic shutdown, professional technology, simple operation, especially suitable for laboratory and field use.

Features

Chinese settings menu

Stainless steel body

Nickel-plated piston with sliding sleeve

Digital display of direct reading power value

Peak hold

The surface is corrosion-resistant electrostatic spraying

5-segment polyline correction

Data storage

High-precision sensors

High-pressure seals

Automatic power off

Self-centering springs

Ultra-low power consumption, continuous work for more than 200 hours

Application

Runjie Tiandi RJ-VX-3 light pull-out instrument is suitable for testing the pull-out strength of various anchors, steel bars (planting bars), expansion bolts, chemical anchors and other anchors, and can also be used for on-site pull-out force testing (test) of glass curtain walls, which is a testing instrument required by various quality inspection and construction units.

Meets standards

   GB 50203-2011 Code for Acceptance of Construction Quality of Masonry Structure Engineering

   JGJ 145-2013

Pictures

Runjie Tiandi RJ-VX-3 light puller display diagram
